Synchronous Cleaning Machine
Synchronous Cleaning
High efficiency and uniform performance
Can integrated with machine tool
Used for pre & post welding cleaning
Interlayer cleaning of multi-pass welding of thick plates
Derniers produits
Effective Cleaning
Synchronous cleaning machine using high-energy laser beam to quickly remove the oxidized layer of the metal surface, clean and efficient.
Uniform Cleaning
The cleaning effect is uniform, without damaging the substrate, and it is environmentally friendly with no residues.
Synchronous Cleaning
Balancing pre-weld oxide film removal and post-weld black residue cleaning, this process enhances efficiency and reduces costs.
Automated Cleaning
Can be integrated into automated machine tools to achieve large-scale cleaning operations.
Paramètres du produit
Product Name | Synchronous Cleaning Machine |
Laser Average Power | 100W/200W/300W/500W |
Laser Center Wavelength | 1064nm |
Scan Width | 5mm ~ 100mm adjustable |
Cooling Mode | Water cooling and cabinet air conditioner |
Product Dimensions | 966mm(L)×400mm(W)×680mm(H) |
Net Weight | about 90kg / 210kg |
Coding Head Weight | about 3kg / 5kg |
Mains Power Frequency | 50Hz |
Power Consumption@25℃ | ＜1.5kW / ＜2kW / ＜3kW / <6kW |
Domaines d'application
Synchronous cleaning machine can be used for pre & post welding cleaning of most metal parts, interlayer cleaning of multi-layer multi-pass welding of thick plates, interlayer cleaning in the process of additive manufacturing, especially in the cleaning of oxide film before MIG welding of aluminum alloys, and the cleaning of black oxides after welding, which has been realized in mass application.
